DFG-30A-B8/T

DFG-30A-B8/T performance parameter
name Industrial frequency screw compressor model DFG-30A-B8/T
displacement，m3/min 3.6 Exhaust pressure，Mpa 0.8
opening pressure of safety valve，Mpa 0.96 Temperature at the outlet of the cooler，℃ ≤Environmental temperature+15
Exhaust oil content，mg/m3 2～4 Lubricant quantity，L 30
Compressed medium air Transmission mode flexible coupling
Motor model YE2—160L2-2 motor speed，r/min 2930
Motor rated power，KW 22 Motor power specifications 380V/50Hz/3P
Protection class IP54 Motor service coefficient 1.2
Insulation Class F Motor starting method Y-△ Voltage reduction startup
Compressor cooling method forced air cooling Compressor control mode intelligent controller
Cooling fan power(W) 1100 Cooling air volume, m3/h 8000
Compressor noise dB（A） 72±3 Exhaust port size Rp1-1/4
External dimensions（L×W×H）mm 1300×880×1150 weight（Kg） 540
