OTV-250W-B8

OTV-250W-B8 Parameter Table
name Water cooled two-stage permanent magnet screw compressor model OTV-250W-B8
displacement，m3/min 41.0 Exhaust pressure，Mpa 0.8
opening pressure of safety valve，Mpa 0.96 Temperature at the outlet of the cooler，℃ ≤40
Exhaust oil content，mg/m3 2～4 Lubricant quantity，L 160
Compressed medium air Transmission mode flexible coupling
Motor model TYCP315M-8 motor speed，r/min 1500
Motor rated power，KW 185 Motor power specifications 380V/100Hz/3P
Protection class IP54 Motor service coefficient 1.3
Insulation Class F Motor starting method Variable frequency start
Type AC100-T3-200K Inverter brand Weichuang
Protection level of frequency converter IP20 Maximum output current of frequency converter 380A
Compressor cooling method water-cooling Compressor control mode intelligent controller
Cooling fan power(W) 1100 Cooling air volume, m3/h 8000
Cooling water volume，T/h 20 Inlet and outlet pipe flange DN50 PN16  HG/T20592
Compressor noise dB（A） 79±3 Exhaust port size flange DN100 PN16  HG/T20592
External dimensions（L×W×H）mm 3500×2114×2280 weight（Kg） 5600
